SEGEL F1311 — Polyester-Based Chemical Anchor

SEGEL F1311 is a versatile polyester-based chemical anchor designed for medium-load anchoring in masonry, hollow bricks, stone, and concrete. It delivers rapid curing, strong adhesion, and reliable performance for interior installations, cabinetry, and decorative fixtures.

Technical Specifications

Parameter	Value
Chemistry	Polyester
Torque Resistance	Up to 52 Nm
Setting Time	4 minutes
Full Cure	25 minutes
Tensile Strength	8.2 ton/m³
Appearance	Grey
Substrates	Hollow brick, solid brick, stone, concrete

Typical Applications

• Anchoring marble, granite, and natural stone
• Decorative wall and ceiling panel installation
• Kitchen cabinet and bathroom fixture anchoring
• Mounting on hollow brick or briquette walls
• General interior installation and repair
• Medium-strength bonding for furniture hardware

• Medium-load anchoring performance
• Strong bonding on stone, concrete, brick, and hollow blocks
• Fast setting and quick handling times
• High torque resistance
• Compatible with most standard caulking guns
• Ideal for interior and decorative applications
• Suitable for non-structural and semi-structural fixings
• Clean and easy injection application

1. Drill a hole to the required diameter and depth.
2. Clean dust from the hole using a blower or brush.
3. Inject the adhesive starting from the back of the hole.
4. Insert the threaded rod or rebar with a gentle twisting motion.
5. Allow the anchor to set before applying load.

SEGEL F1711 — Epoxy Acrylic Chemical Anchor

SEGEL F1711 is a high-performance epoxy-acrylate chemical anchor designed for medium-to-heavy load applications. It offers superior strength, excellent durability, and outstanding performance on cracked and non-cracked concrete. Suitable for both indoor and outdoor structural fixings.

Technical Specifications

Parameter	Value
Chemistry	Epoxy Acrylic
Torque Resistance	Up to 200 Nm
Setting Time	3 minutes
Full Cure	35 minutes
Tensile Strength	9.5 ton/m³
Appearance	Grey
Substrates	Concrete, reinforced concrete, stone

Typical Applications

• Railings and handrails
• Balcony and staircase supports
• Pipe supports, electrical and ventilation systems
• Safety fences, barriers, and signage
• Machinery subjected to vibration
• Steel frames and mounting plates
• Rebar connection and concrete reinforcement
• Canopy and structural fittings

• Suitable for cracked & non-cracked concrete
• High tensile and shear strength
• Excellent performance under vibration and dynamic loading
• No expansion stress (does not damage concrete)
• Can be used close to edges without cracking
• Adjustable positioning before curing
• Ideal for structural and semi-structural anchoring
• Suitable for outdoor environments

1. Drill the hole according to anchor diameter.
2. Clean out all dust and debris thoroughly.
3. Inject the chemical anchor into the hole.
4. Insert the rod or rebar while rotating.
5. Allow full curing before applying load.
